Поставка оригинальных INA333AIDGKR, Линейные - Усилители - Инструментальные, Операционные усилители, Буферные усилители, от Texas Instruments

Description
The INA333AIDGKR is a low-power, Precision Instrumentation Amplifier offers excellent accuracy.
The versatile 3 operational amplifier design, small size and low power make it ideal for a wide range of portable applications. A single external resistor sets any gain from 1 to 1000.
The INA333AIDGKR is designed to use an industry-standard gain equation - G = 1 + (100kR/RG).
The INA333AIDGKR provides very low offset voltage (25µV, G >=100), excellent offset voltage drift (0.1µV/°C, G >=100) and high common-mode rejection (100dB at G >=10). It operates with power supplies as low as 1.8V (±0.9V) and quiescent current is only 50µA - ideal for battery-operated systems. Using auto calibration techniques to ensure excellent precision over the extended industrial temperature range, the INA333AIDGKR also offers exceptionally low noise density (50nV/√Hz) that extends down to DC.
Features 50nV/√Hz, G >=100 Low noise100dB Minimum, G >=10 high CMRR200pA Maximum low input bias current(V-) +0.1 to (V+) -0.1V Input voltage(V-) +0.05 to (V+) -0.05V Output range50µA Low quiescent currentRFI filtered inputsGreen product and no Sb/Br Application Audio, Sensing & Instrumentation, Medical, Portable Devices, Test & Measurement
