Description CD4555BMS and CD4556BMS are dual one-of-four decod ers/demultiplexers. Each decoder has two select inputs (A and B), an Enable input (E), and four mutually exclusive out puts. On the CD4555BMS the outputs are high on select; on the CD4556BMS the outputs are low on select. When the Enable input is high, the outputs of the CD4555BMS remain low and the outputs of the CD4556BMS remain high regardless of the state of the select inputs A and B.
The CD4555BMS and CD4556BMS are similar to types MC14555 and MC14556, respectively.
Features
• High Voltage Type (20V Rating)
• CD4555BMS: Outputs High on Select
• CD4556BMS: Outputs Low on Select
• Expandable with Multiple Packages
• 100% Tested for Quiescent Current at 20V
• Standardized, Symmetrical Output Characteristics
• Maximum Input Current of 1µA at 18V Over Full Pack age Temperature Range; 100nA at 18V and +25oC
• Noise Margin (Over Full Package/Temperature Range) - 1V at VDD = 5V - 2V at VDD = 10V - 2.5V at VDD = 15V
• 5V, 10V and 15V Parametric Ratings
• Meets All Requirements of JEDEC Tentative Standard No. 13B, “Standard Specifications for Description of ‘B’ Series CMOS Devices” Applications
• Decoding
• Code Conversion
• Demultiplexing (Using Enable Input as a Data Input
• Memory Chip-Enable Selection
• Function Selection
