Поставка оригинальных DF13-30DS-1.25C, Rectangular Connectors - Housings, от Hirose

The DF13-30DS-1.25C is a connector manufactured by Hirose Electric Co., Ltd., known for its high-quality interconnect solutions. This specific connector is part of the DF13 series, which is designed for compact and reliable connections in various electronic applications.

Detailed Description:

1. Type and Configuration:

   • The DF13-30DS-1.25C is a 30-position (30 pins) connector, which means it has 30 individual contact points for electrical connections.
   • It is a dual-row connector, allowing for a more compact design while maintaining a high pin count.

2. Pitch:

   • The pin pitch (the distance between the centers of adjacent pins) is 1.25 mm, which is relatively small, making it suitable for applications where space is at a premium.

3. Mounting Style:

   • This connector is designed for surface mount technology (SMT), allowing it to be mounted directly onto the surface of a printed circuit board (PCB). This feature enhances the overall design flexibility and reduces the footprint of the assembly.

4. Contact Material:

   • The contacts are typically made from a copper alloy, which provides good electrical conductivity and durability. The surface finish may include gold plating to enhance corrosion resistance and ensure reliable electrical performance.

5. Insulation Material:

   • The housing is usually made from a high-quality thermoplastic material, which provides excellent insulation properties and mechanical strength. This material is often rated for high-temperature applications, ensuring reliability in various environments.

6. Locking Mechanism:

   • The DF13 series connectors often feature a locking mechanism that ensures a secure connection between the mating halves. This is crucial in applications where vibration or movement could otherwise lead to disconnection.

7. Applications:

   • The DF13-30DS-1.25C connector is commonly used in consumer electronics, telecommunications, automotive applications, and industrial equipment. Its compact size and reliable performance make it ideal for devices such as smartphones, tablets, and other portable electronics.

8. Electrical Ratings:

   • The connector typically supports a voltage rating of around 50V and a current rating of approximately 1A per contact, making it suitable for low to moderate power applications.

9. Environmental Considerations:

   • The connector is designed to withstand various environmental conditions, including temperature extremes and humidity, making it suitable for a wide range of applications.

In summary, the DF13-30DS-1.25C from Hirose is a versatile, compact, and reliable connector that is well-suited for modern electronic devices requiring efficient space utilization and dependable performance. Its design features and materials make it a popular choice among engineers and designers in various industries.
