LMV431BIMF/NOPB PMIC - Источник опорного напряжения от Texas Instruments

The LMV431BIMF/NOPB is a precision voltage reference and adjustable shunt regulator manufactured by Texas Instruments. It is designed for applications requiring a stable reference voltage and is particularly useful in power management and signal conditioning circuits.

Key Features:

1. Voltage Reference: The LMV431 provides a precise reference voltage that can be adjusted from 1.24V to 36V, making it versatile for various applications.

2. Shunt Regulator: It operates as a shunt regulator, allowing it to maintain a constant output voltage despite variations in load current or input voltage.

3. Low Output Impedance: The device features low output impedance, which helps maintain stability and accuracy in the output voltage under varying load conditions.

4. Temperature Stability: The LMV431 is designed for excellent temperature stability, ensuring that the reference voltage remains consistent across a wide temperature range.

5. High Accuracy: With a typical initial accuracy of ±1%, the LMV431 provides reliable performance for precision applications.

6. Wide Operating Range: The device can operate over a wide range of supply voltages, making it suitable for various power supply designs.

7. Compact Package: The LMV431BIMF/NOPB is available in a small form factor, typically in a SOT-23 package, which is ideal for space-constrained applications.

8. Low Power Consumption: It features low quiescent current, which is beneficial for battery-powered devices and energy-efficient designs.

9. Application Versatility: Common applications include power supplies, battery management systems, and as a reference in analog-to-digital converters (ADCs).

Electrical Characteristics:

• Reference Voltage (Vref): 1.24V (typical)
• Adjustable Output Voltage Range: 1.24V to 36V
• Temperature Coefficient: Low, ensuring minimal drift with temperature changes
• Operating Temperature Range: Typically from -40°C to +125°C
• Supply Voltage Range: Compatible with a wide range of input voltages

Pin Configuration:

The LMV431 typically features three pins:

• Ref: Reference voltage output
• Anode: Connects to the load
• Cathode: Connects to the input voltage

Applications:

• Power supply regulation
• Voltage reference for ADCs
• Battery management systems
• Signal conditioning circuits
• Precision measurement systems

Conclusion:

The LMV431BIMF/NOPB from Texas Instruments is a highly reliable and versatile voltage reference and shunt regulator, making it an excellent choice for engineers looking to implement precise voltage regulation in their designs. Its combination of accuracy, stability, and low power consumption makes it suitable for a wide range of electronic applications.
