Поставка оригинальных LMV393DMR2G, Линейные - Компараторы, от ON Semiconductor

The LMV331 is a CMOS single channel, general purpose, low voltage comparator.
The LMV393 and LMV339 are dual and quad channel versions, respectively.
The LMV331/393/339 are specified for 2.7 V to 5 V performance, have excellent input common−mode range, low quiescent current, and are available in several space saving packages.
Features
• Guaranteed 2.7 V and 5 V Performance
• Input Common−mode Voltage Range Extends to Ground
• Open Drain Output for Wired−OR Applications
• Low Quiescent Current: 60 A/channel TYP @ 5 V
• Low Saturation Voltage 200 mV TYP @ 5 V
• Propagation Delay 200 ns TYP @ 5 V
• NCV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q100 Qualified and PPAP Capable
•
These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS CompliantTypical Applications
• Battery Monitors
• Notebooks and PDA’s
• General Purpose Portable Devices
• General Purpose Low Voltage Applications
