The NB4N316M is a differential Clock or Data receiver and will accept AnyLevel input signals: LVPECL, CML, LVCMOS, LVTTL, or LVDS.
These signals will be translated to CML, operating up to 2.0 GHz or 2.5 Gb/s, respectively. As such, the NB4N316M is ideal for SONET, GigE, Fiber Channel, Backplane and other Clock or Data distribution applications.
Features
• Maximum Input Clock Frequency > 2.0 GHz
• Maximum Input Data Rate > 2.5 Gb/s
• Typically 1 ps of RMS Clock Jitter
• Typically 10 ps of Data Dependent Jitter
• 550 ps Typical Propagation Delay
• 150 ps Typical Rise and Fall Times
• Differential CML Outputs
• 25 mV of Receiver Input Threshold Hysteresis
• Operating Range: VCC = 3.0 V to 3.6 V with VEE = 0 V and VTT = 1.8 V to 3.6 V
• Functionally Compatible with Existing 2.5 V / 3.3 V LVEL, LVEP, EP, and SG Devices
• −40°C to +85°C Ambient Operating Temperature
•
These are Pb−Free Devices
*
