EPM7128STC100-10 Встраиваемые ПЛИС (Программируемые логические интегральные схемы) от Intel

The MAX 7000 family of high-density, high-performance PLDs is based on Altera’s second-generation MAX architecture. Fabricated with advanced CMOS technology, the EEPROM-based MAX 7000 family provides 600 to 5,000 usable gates, ISP, pin-to-pin delays as fast as 5 ns, and counter speeds of up to 175.4 MHz.
Features...
• High-performance, EEPROM-based programmable logic devices (PLDs) based on second-generation MAX® architecture
• 5.0-V in-system programmability (ISP) through the built-in IEEE Std. 1149.1 Joint Test Action Group (JTAG) interface available in MAX 7000S devices
– ISP circuitry compatible with IEEE Std. 1532
• Includes 5.0-V MAX 7000 devices and 5.0-V ISP-based MAX 7000S devices
• Built-in JTAG boundary-scan test (BST) circuitry in MAX 7000S devices with 128 or more macrocells
• Complete EPLD family with logic densities ranging from 600 to 5,000 usable gates (see Tables 1 and 2)
• 5-ns pin-to-pin logic delays with up to 175.4-MHz counter frequencies (including interconnect)
• PCI-compliant devices available
• Open-drain output option in MAX 7000S devices
• Programmable macrocell flipflops with individual clear, preset, clock, and clock enable controls
• Programmable power-saving mode for a reduction of over 50% in each macrocell
• Configurable expander product-term distribution, allowing up to 32 product terms per macrocell
• 44 to 208 pins available in plastic J-lead chip carrier (PLCC), ceramic pin-grid array (PGA), plastic quad flat pack (PQFP), power quad flat pack (RQFP), and 1.0-mm thin quad flat pack (TQFP) packages
• Programmable security bit for protection of proprietary designs
• 3.3-V or 5.0-V operation
– MultiVoltTM I/O interface operation, allowing devices to interface with 3.3-V or 5.0-V devices (MultiVolt I/O operation is not available in 44-pin packages)
– Pin compatible with low-voltage MAX 7000A and MAX 7000B devices
• Enhanced features available in MAX 7000E and MAX 7000S devices
– Six pin- or logic-driven output enable signals
– Two global clock signals with optional inversion
– Enhanced interconnect resources for improved routability
– Fast input setup times provided by a dedicated path from I/O pin to macrocell registers
– Programmable output slew-rate control
• Software design support and automatic place-and-route provided by Altera’s development system for Windows-based PCs and Sun SPARCstation, and HP 9000 Series 700/800 workstations
• Additional design entry and simulation support provided by EDIF 2 0 0 and 3 0 0 netlist files, library of parameterized modules (LPM), Verilog HDL, VHDL, and other interfaces to popular EDA tools from manufacturers such as Cadence, Exemplar Logic, Mentor Graphics, OrCAD, Synopsys, and VeriBest
• Programming support
– Altera’s Master Programming Unit (MPU) and programming hardware from third-party manufacturers program all MAX 7000 devices
–
The BitBlasterTM serial download cable, ByteBlasterMVTM parallel port download cable, and MasterBlasterTM serial/universal serial bus (USB) download cable program MAX 7000S devices
