Поставка оригинальных DMP3056LDM-7, Транзисторы - Полевые транзисторы, MOSFET - Одиночные, от Diodes Incorporated

The DMP3056LDM-7 is a N-channel MOSFET (Metal-Oxide-Semiconductor Field-Effect Transistor) manufactured by Diodes Incorporated. This component is designed for use in various electronic applications, including power management, switching, and amplification.

Key Features:

1. Type: N-channel MOSFET
2. Package: The DMP3056LDM-7 is typically housed in a compact SOT-23 package, which is suitable for surface mount technology (SMT). This small footprint makes it ideal for space-constrained applications.
3. Voltage Rating: The device has a maximum drain-source voltage (V_DS) rating of 60V, allowing it to handle a wide range of voltage applications.
4. Current Rating: It can support a continuous drain current (I_D) of up to 30A, making it suitable for high-current applications.
5. R_DS(on): The on-resistance (R_DS(on)) is low, typically around 0.045 ohms at a gate-source voltage (V_GS) of 10V. This low on-resistance contributes to reduced power loss and improved efficiency in switching applications.
6. Gate Threshold Voltage (V_GS(th)): The gate threshold voltage is typically in the range of 1V to 3V, which allows for easy drive with low-voltage control signals.
7. Switching Speed: The DMP3056LDM-7 features fast switching capabilities, making it suitable for high-frequency applications.
8. Thermal Resistance: The device has a low thermal resistance, which helps in managing heat dissipation during operation.

Applications:

The DMP3056LDM-7 is commonly used in various applications, including:

• Power Supply Circuits: It can be used in DC-DC converters and power management systems to efficiently switch power.
• Motor Control: The MOSFET is suitable for driving motors in various applications, including robotics and automotive systems.
• Load Switching: It can be employed in load switching applications where high current and voltage handling is required.
• LED Drivers: The device is also used in LED lighting applications for efficient control of LED currents.

Electrical Characteristics:

• Maximum Gate-Source Voltage (V_GS): ±20V
• Maximum Power Dissipation (P_D): Typically around 1.5W, depending on the thermal management of the PCB.
• Operating Temperature Range: The device can operate in a wide temperature range, typically from -55°C to +150°C.

Conclusion:

The DMP3056LDM-7 from Diodes Incorporated is a versatile and efficient N-channel MOSFET that is well-suited for a variety of electronic applications requiring reliable switching and power management. Its compact size, high current capacity, and low on-resistance make it a popular choice among engineers and designers in the electronics industry.
