IS42S16800F-7TL Память от Integrated Silicon Solution, Inc. (ISSI)

OVERVIEW ISSI's 128Mb Synchronous DRAM achieves high-speed data transfer using pipeline architecture. All inputs and outputs signals refer to the rising edge of the clock input.
The 128Mb SDRAM is organized as follows.
FEATURES
• Clock frequency: 166,143,100 MHz
• Fully synchronous; all signals referenced to a positive clock edge
• Internal bank for hiding row access/precharge
• Power supply VDD VDDQ IS42S81600A 3.3V 3.3V IS42S16800A 3.3V 3.3V IS42S32400A 3.3V 3.3V
• LVTTL interface
• Programmable burst length
– (1, 2, 4, 8, full page)
• Programmable burst sequence: Sequential/Interleave
• Auto Refresh (CBR)
• Self Refresh with programmable refresh periods
• 4096 refresh cycles every 64 ms
• Random column address every clock cycle
• Programmable CASlatency (2, 3 clocks)
• Burst read/write and burst read/single write operations capability
• Burst termination by burst stop and precharge command
• Industrial Temperature Availability
• Lead-free Availability
